Can be either used built-in or independent with clip-on strain-reliefFor luminaires of protection class I and protection class IIFor luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711Temperature protection as per EN 61347-2-13...
Price and stock will be confirmed by LEDDomain Qatar.
Send this item to our team for price, stock and driver compatibility.
Enquire on WhatsAppContact LEDDomain QatarCan be either used built-in or independent with clip-on strain-relief
For luminaires of protection class I and protection class II
For luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711
Temperature protection as per EN 61347-2-13 C5e
Adjustable output current via dip switch or DALI
Selectable fixed output current 350, 400, 450, 500, 550, 600, 650 and 700 mA (pre-selected current 350 mA)
Max. output power 30 W
Up to 88 % efficiency
Nominal lifetime up to 100,000 h
5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions)
Housing properties
Casing: polycarbonate, white
Type of protection IP20
Interfaces
one4all (DALI-2, switchDIM, corridorFUNCTION)
Terminal blocks: 45° push terminals
Functions
Adjustable output current in 1-mA-steps (DALI)
Constant light output function (CLO)
Protective features (overtemperature, short-circuit, overload, no-load)
Suitable for emergency escape lighting systems acc. to EN 50172
Benefits
Flexible configuration via companionSUITE (DALI)
Application-oriented operating window for maximum compatibility
Best energy savings due to low stand-by losses and high efficiency
Typical applications
For downlight, spotlight and decorative applications
Can be either used built-in or independent with clip-on strain-relief
For luminaires of protection class I and protection class II
For luminaires with M and MM as per EN 60598, VDE 0710 and VDE 0711
Temperature protection as per EN 61347-2-13 C5e
Adjustable output current via dip switch or DALI
Selectable fixed output current 350, 400, 450, 500, 550, 600, 650 and 700 mA (pre-selected current 350 mA)
Max. output power 30 W
Up to 88 % efficiency
Nominal lifetime up to 100,000 h
5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions)
Housing properties
Casing: polycarbonate, white
Type of protection IP20
Interfaces
one4all (DALI-2, switchDIM, corridorFUNCTION)
Terminal blocks: 45° push terminals
Functions
Adjustable output current in 1-mA-steps (DALI)
Constant light output function (CLO)
Protective features (overtemperature, short-circuit, overload, no-load)
Suitable for emergency escape lighting systems acc. to EN 50172
Benefits
Flexible configuration via companionSUITE (DALI)
Application-oriented operating window for maximum compatibility
Best energy savings due to low stand-by losses and high efficiency
Typical applications
For downlight, spotlight and decorative applications
