Tridonic Driver LCA 75W 100-400mA one4all lp PRE
Tridonic Driver LCA 75W 100-400mA one4all lp PRE
Regular price
QAR 163,00
Regular price
Sale price
QAR 163,00
Taxes included.
Quantity
Couldn't load pickup availability
- Product description
- Dimmable built-in constant current LED driver
- Dimming range 10 – 100 % (min. 25 mA)
- For luminaires of protection class I and protection class II
- Temperature protection as per EN 61347-2-13 C5e
- Adjustable output current between 250 and 400 mA via I-SELECT 2 plugs
- Max. output power 75 W
- Up to 93 % efficiency
- Power input on stand-by < 0.4 W
- Nominal lifetime up to 100,000 h
- 5 years guarantee (conditions at https://www.tridonic.com/en/int/services/manufacturer-guarantee-conditions)
- Housing properties
- Low profile metal casing with white cover
- Type of protection IP20
- Interfaces
- one4all (DALI-2 DT 6, DSI, switchDIM, corridorFUNCTION V2)
- Terminal blocks: 0° push terminals
- Functions
- Adjustable output current in 1-mA-steps (I-SELECT 2)
- Protective features (overtemperature, short-circuit, overload, no-load, input voltage range)
- Suitable for emergency escape lighting systems acc. to EN 50172
- Benefits
- Application-oriented operating window for maximum compatibility
- Typical applications
- For linear/area lighting
